Dynamic Condylar Screw Plate
Dynamic Condylar Screw Plate is designed to provide strong and stable internal fixation of certain distal femoral and subtrochanteric fractures, with minimal soft tissue irritation.
Dynamic Condylar Screw Plate Uses
The Dynamic Condylar Screw Plate Plate is indicated for the following fractures of the proximal distal:
Intercondylar fractures
Supracondylar fractures
Unicondylar fractures
The Dynamic Condylar Screw Plate Plate is indicated for the following fractures of the proximal femur:
Transverse subtrochanteric fractures
Short oblique subtrochanteric fractures
Long oblique subtrochanteric fractures
Plates are made of 316L stainless steel and Titanium.
The Dynamic Condylar Screw Plate are available with 6, 7, 8, 10, 12, 14, 16, 18, and 20 holes, for varied clinical situations.
The number of screw holes per plate length is maximized, without compromising plate strength. This allows an increased number of fixation points with a smaller incision.
The two holes closest to the barrel accept 6.5 mm cancellous bone screws. This enhances stability by allowing additional fixation of the most distal condylar fracture fragments or fixation of the most proximal subtrochanteric fracture fragments.
Screw holes in the plate shaft allow angulation of 4.5 mm cortex screws and axial compression across a shaft fracture.
The lag screw is available in 50 mm to 145 mm lengths. The compression screw can be used for additional compression; only one size compression screw is needed.
Two flats within the plate barrel correspond to the two-flat design of the lag screw, preventing rotation of the lag screw within the barrel. The two-flat design also eases insertion of the plate over the lag screw.
The plates have a low-profile design, reducing the risk of iliotibial band irritation (distal femoral fractures) and trochanteric bursitis (subtrochanteric fractures).
The Dynamic Condylar Screw Plate instruments also provide direct measurements throughout the procedure, allowing proper reaming, tapping, and lag screw insertion depth. The built-in stop and locking nut on the triple reamer prevent over-reaming.
General Instruments are available for this plate such as Plate Bending Press, Plate Holding Forceps, Plate Bending Pliers, Bone Holding Forceps, Bone Elevators, Bone Cutter, Bone Nibbler, Depth Gauge, Sleeve, Screw Driver, Trocar Sleeve etc.
